Catálogo Seccionadores y contactores modulares HSD & HIC

Hyundai Electric

Catálogo Seccionadores y contactores modulares HSD & HIC

Publicado: 21 de julio de 2026 · Categoría: Catálogos

De este documento

HSD Miniature Switch Disconnector Feature  42 Selection Table  44 Dimension  46 Order Information 48 Feature HSD Miniature Switch Disconnector HD HYUNDAI ELECTRIC introduces the HSD series of MSDs rating from 6 A to 125 A. They are switch disconnectors with independent manual operation, capable of making, carrying and breaking currents under normal circuit conditions, which may includes operating under overload condition. They also carry currents under specified abnormal circuit conditions such as those of short circuit for a specified time. 42 HG Modular Devices Product Feature Hyundai HSD type switch disconnectors are mainly used for isolation and switching in the terminal combined electric appliances under the alternating current 50/60 Hz, rated voltage AC 240 V or AC 415 V and with rated current 6 to 125 A. The double point direct moving structure enlarges the current capacity while making full use of the electrical power supplement. In addition, power reserving handle mechanism with high on/off speed promotes the working reliability. HSD type breakers comply with IEC/EN standard, and can be applied to industry, commerce, high-rise buildings, household and other similar installations. Deluxe Type Standard Type Product Performance - Longer electrical life - Low power consumption, thus cost effective&energy saving - To avoid improper cable termination, the safety terminals guide the cable towards the cage terminal for systematic termination - Low watt loss - Wide...
